Relay Test Set Features Analog/Digital Recorder, Measurement Function

Feb. 15, 2011
ISA's advanced relay test set DRTS 66 features Transcope, now available on request.

ISA's advanced relay test set DRTS 66 features Transcope, now available on request. Transcope is an analog/digital recorder and measurement function.

The DRTS 66 family of test sets can be orderd with measurement and recording of:

  • 10 voltages or currents (with clamps or external shunts) AC and DC meter and recorder.
  • Phase angle, wattmeter, frequency, harmonics meter, power quality meter.
  • Oscilloscope functions.
  • Sequence of Event recorder (up to 10 digital inputs).
  • Fault recording function.

Maximum recording duration:

  • at 5 kHz: 6 min for 1 input channel / 40 s for 10 input channels.
  • at 50 kHz: 40 s for 1 input channel / 4 s for 10 input channels.

This option is to be specified at order.
