NREL Storage Futures Study Outlines Framework for Increase in Deployment

Feb. 5, 2021
The first report in the multi-year study presents four phases of utility-scale energy storage deployment, provides a roadmap to 100+ GW of installed capacity.

With declining costs, improved technologies and increasing deployment, energy storage is poised to become a growing part of the evolving U.S. power system. But measuring the value of energy storage is inherently complex — and future systems will likely include multiple storage technologies, adding new complexity. To answer the big questions around the role of storage in our future grid, the National Renewable Energy Laboratory (NREL) has launched the multiyear Storage Futures Study (SFS). Supported by the U.S. Department of Energy's (DOE's) Energy Storage Grand Challenge, the study explores how energy storage technology advancement could impact the deployment of utility-scale storage and adoption of distributed storage, as well as future power system infrastructure investment and operations.

In the first report in the series, The Four Phases of Storage Deployment: A Framework for the Expanding Role of Storage in the U.S. Power System, NREL analysts Paul Denholm, Wesley Cole, Will Frazier and Nate Blair, along with DOE analyst Kara Podkaminer, outline a visionary framework for the possible evolution of the stationary energy storage industry — and the power system as a whole. The framework presents a value proposition of cost-competitive storage deployment in four phases, potentially resulting in hundreds of gigawatts of installed capacity and a significant shift in the U.S. power grid.

"To ensure cost-optimal deployment of storage technologies, we need careful analysis," said Nate Blair, SFS project lead and group manager of the Distributed Systems and Storage Group in NREL's Strategic Energy Analysis Center. "The Storage Futures Study — specifically this vision for four phases of storage deployment — uses trends, projections and analyses to develop a first-of-its-kind framework to help utilities, regulators and developers prepare for the future."

Phase One: Short-duration storage to provide operating

Assuming the cost of most storage technologies increases with duration, the analysts make a case for deployments following a natural progression from shorter to longer duration over time, particularly aligned with current and anticipated growth in photovoltaics and wind power. Phase One builds on the long history of energy storage on the grid that has been primarily supplied by pumped storage hydro and which is by far the dominant source of energy storage today with 22 GW installed on the U.S. electric grid.

In Phase One of the proposed framework, short-duration storage provides operating reserves to the grid — increasing or decreasing output for a short amount of time to help maintain the balance of supply and demand on the grid.

"Phase One of storage deployment has already been underway since the early 2000s, when wholesale markets allowed for storage to directly compete with traditional resources," said Paul Denholm, NREL analyst and developer of the framework. "This has resulted in significant deployments of energy storage in the U.S. of durations of one hour or less."

Monetization of existing frequency response requirements, additional market products and growth in regulating reserves from variable generation could increase the deployment of storage in phase one.

Phase Two: The rise of battery peaking power plants

Falling battery prices have introduced the opportunities for Phase Two — the deployment of batteries with 2-6 hours of duration to meet peak demand on hot summer days or in extreme cold.

Batteries' cost-competitiveness is based on their ability to provide the same level of peaking capacity compared with traditional resources such as gas turbines. NREL analysts found significant opportunities for batteries with four-hour durations.

In this phase, the cost-competitiveness of battery storage increases with hybrid system configurations, where storage is co-located with renewable generation sources, particularly solar photovoltaics, to receive an investment tax credit. In addition, cost-competitiveness increases when demand for additional capacity increases or traditional sources retire.

Phase Three: The age of low-cost diurnal storage

Decreased value of shorter-duration capacity marks the transition to Phase Three — the advent of storage technologies that can provide additional or lower-cost services to meet longer peak periods.

"In this phase, shorter-duration storage plants can still provide capacity at a reduced capacity credit," Denholm said. "Various system configurations can offset the reduced capacity credit through opportunities like absorbing curtailed energy in a high-solar future."

Phase Three largely depends on how much storage costs decline and variable renewable energy deployment increases. At higher levels of variable generation deployment, cost-effective storage with up to 12 hours of duration could potentially provide significant amounts of capacity-related services.

Longer-duration storage can provide other services that add flexibility to the grid, like supporting transmission from remote wind generation sites.

Phase Four: The end game — multiday to seasonal storage

The final phase of NREL's vision for storage deployment introduces seasonal storage, driven by the seasonal mismatch of variable resource supply and demand, particularly in a deep-decarbonization future that relies heavily on renewable resources.

Seasonal storage would mitigate this imbalance by shifting excess renewable energy available in the spring to times of higher demand and/or lower availability of renewable resources.

There are a variety of technologies that can be built for seasonal or long-duration storage. Compressed air and pumped storage hydropower have already been deployed at scale. Other technologies involve producing hydrogen, methane or other fuels that can be stored underground for months or years. In this phase, when and how much seasonal storage is deployed largely depends on the competitiveness and declining costs of these or other emerging technologies.

Coming Next: More from the storage futures study

The first report provides a foundational framework for future SFS analyses. "Our four-phase framework is intended to describe a plausible evolution of cost-competitive storage technologies, but more importantly, it identifies key elements needed for stakeholders to evaluate alternative pathways for both storage and other sources of system flexibility," Denholm said.

Many concepts presented in this vision will be further explored in upcoming studies, including detailed results of the modeling and analysis of power system evolution scenarios and their operational implications.

Improved characterization of various grid services needed, including capacity and duration, could support a deeper understanding of the trade-offs between various technologies and non-storage resources such as responsive demand. This would help ensure the mix of flexible technologies deployed is robust to an evolving grid, which will ultimately determine the amount of storage and flexibility the power system will need.

Visit the Storage Futures Study page to learn more.
