Reliability Analysis of U.S. West Reviews Barriers to Renewable Future

Feb. 5, 2021
NREL assesses long-term reliability and integration impacts of solar PV growth in the western United States.

The Western Interconnection is an electric grid that connects power from Canada down to Baja California, and from the Great Plains to the Pacific. It also represents an electric system in transition: a steady increase in renewable energy sources, especially solar photovoltaics (PV), is presenting choices today with impacts that will last for decades. As part of a multistate collaboration, the National Renewable Energy Laboratory (NREL) has modeled and assessed long-term reliability and integration impacts of solar PV growth in the western United States, with broader lessons for power grids and renewable policies.

The newly published reports cap the NREL's contributions in support of the Western Interstate Energy Board's (WIEB's) project named Enhanced Distributed Solar Photovoltaic Deployment via Barrier Mitigation or Removal in the Western Interconnection, funded by the U.S. Department of Energy (DOE) Solar Energy Technologies Office, and in collaboration with Lawrence Berkeley National Laboratory.

"The rapid growth of distributed solar PV generation in the West presents valuable opportunities to help states meet their clean energy goals but also presents potential challenges related to interconnection, reliability, and rate-design barriers," said WIEB Director of State, Federal, and International Affairs Holly Taylor. "The WIEB was proud to partner with research scientists at the NREL in an effort to identify opportunities that mitigate electric system reliability barriers to PV deployment, and to bring the findings of this important work to the WIEB's western state partners."

The NREL's latest reports specifically target reliability issues that future grids will — and already do — face. The reliability issues were decided with input from the project's technical advisory committee, which included stakeholders from many utilities, regional and national regulators, grid system operators, and independent analysis groups.

"It was a unique experience to step back and gather information from internal and external experts during project start-up," said Elaine Hale, the project lead at the NREL. "From that firm grounding, we were able to study and present analysis on a range of timely issues."

The project team narrowed the potential challenges into four categories: bulk dispatch, system planning, dynamic stability, and the distribution grid. These categories were used to focus NREL analysis on several facets of grid reliability, which were published in the series of NREL reports. Summaries of the reports follow.

Power System Flexibility

In the report titled Power System Flexibility Requirements and Supply, the project team considered the quantity of power system flexibility in the West and its sufficiency for managing significant growth in solar PV (see Fig. 1). Following an analysis that applied the NREL's Resource Planning Model (RPM), as well as PLEXOS for simulating electricity production, the NREL found that the Western Interconnection has considerable inherent flexibility and under the PV integration scenarios studied, there is plenty of ramping ability to manage fluctuations in net load.

However, the authors note that flexibility in the Western Interconnection is heavily dependent on transmission between regions — the dominant sources of ramping vary by region and each region's flexibility is dependent on one another's ramping capability.

Resource Adequacy

Another of the NREL reports, titled Resource Adequacy Considerations, studies the availability of resources to serve future loads during peak and other stressful conditions. In this report, the NREL's Probabilistic Resource Adequacy Suite provided a probabilistic check of the RPM's heuristic methods for planning resources and estimating the firm capacity contribution of PV. The NREL found that the Western Interconnection is overbuilt in general, with "extremely high levels of capacity adequacy," and that the future buildouts computed by the NREL's models appear to have sufficient resources to serve peak net load with PV penetrations of up to 33% under the conditions that the NREL simulated.

Indeed, the authors suggest that the planning reserve constraints used in the RPM may be conservative, leading to possibly higher-than-necessary investment in capacity resources. Caution is in order, however, as the authors also note that a more accurate representation of the grid's planning reserve needs could be achieved through studies that test the NREL's results under a wider range of system operating conditions and use more detailed representations of transmission and energy-limited resources.

Transmission Contingencies

Another report studied distribution-level impacts stemming from simulated faults on real Western Interconnection transmission paths. Specifically, the report models the outcome of different distributed energy resource (DER) responses defined under various revisions of standard IEEE 1547. Depending on the specific response criteria selected under the framework of IEEE 1547, the report finds that DERs could ride through transmission-level faults associated with wide-area and prolonged voltage events, thereby limiting their impact on power reliability by keeping more distributed generation online both during and subsequent to a disturbance. The report is titled Simulating Distributed Energy Resource Responses to Transmission System-Level Faults Considering IEEE 1547 Performance Categories on Three Major WECC Transmission Paths.

Behind-the-Meter Solar Accounting

The report titled Behind-the-Meter Solar Accounting in Renewable Portfolio Standards reveals how different accounting strategies might affect progress toward renewable portfolio standard (RPS) goals. The study examines accounting choices including whether a state recognizes the loads served by behind-the-meter solar within its RPS, and whether behind-the-meter solar is counted as renewable generation within the RPS. The NREL found that a common accounting practice among states actually has the potential to decrease the total amount of renewable generation in the state relative to if there were no behind-the-meter generation, if the RPS is binding.

Power Inverter Influences on Stability

Related to the dynamic stability of power systems served by inverter-based resources, the article titled Stability and Control of Power Systems with High Penetrations of Inverter-Based Resources: An Accessible Review of Current Knowledge and Open Questions reviews literature describing what may be required to transition from spinning inertia associated with traditional generation, to mostly inverter-based power systems. The review serves as a handy reference for grid operators and planners.

Learn more about bulk grid reliability research and analysis at the NREL.
